TürkçeBioPass PRO ''Fingerprint + Contactless Card Reader''
BioPass PRO ''Fingerprint + Contactless Card Reader''
BioPASS Pro Fingerprint Reader is designed for Attendance, Access Control and Cafeteria systems with fingerprint and card (Prox. or Mifare +PIN) reading features. It has a reliable, accurate and excellent verification speed with its special algorithm. The smart and manageable biometric fingerprint reader system, which can especially work ONLINE or OFFLINE, is the only fingerprint reader system that has the feature of logging in and out based on the authority defined in the Attendance program.
HARDWARE FEATURES
Input Voltage: 8V - 28V, Screen: TFT (320*240) 3.5', Ethernet: 10/100 Mbps, Optional (Poe 8V - 60V), CPU: 120MHz 32 Byte Cortex-M4, Keypad: YES (Touch) Buzzer, Optical Input, Solid State Relay, RTC, Temperature Sensor, Operating Temperature: (-20, +70), External Communication: (12C, UART, SPI, GPIOx5, Analogx2)
RF FEATURES
RF Operating Frequency: 125 KHz or 13.56 MHz, RF Reading Distance: 2 - 10cm, Card Support: Proximity or MIFARE Classic: 1K/4K, Standard Support ISO 14443 A/B,
OPERATING FEATURES
Working Mode: Online or Offline, Antipassback feature via Mifare card, Pass with Excuse Notification, Cards Per Person: 3, Person Based Pass Modes, Sequential Reading Control, Zone Control Pass: Only with Card*, Card User Memory: 100,000i Fingerprint memory: 3,000, Transition Movements Memory: 125,000, device movements memory: 29,000, Authorized Person Registration Memory: 15,000, Blacklist Memory: 8,000, Rights Definition Table: 24 Hours * 78 different groups, Automatic On-Off, Personal Message, Announcement Broadcast, Automatic sending of Offline Records Online, Theme Selection, Remote Update
HARDWARE FEATURES |
|
|---|---|
| CPU : | 120MHz 32 Bit Cotex M3 |
| Working Temperature: | -20, +70 |
| Input Voltage: | 8V-28V (Poe 8V-60V) |
| Fingerprint Reader: | Yes |
| Screen TFT: | (320*240) 3.5′ |
| Communication: | TCP/IP - Optional RS485, RS232 |
WORKING FEATURES |
|
| Device Transaction Capacity: | 29.000 |
| Blacklist: | 8.000 |
| Remote Updating: | Yes |
| Fingerprint Reader User Capacity : | 3.000 |
| Working Mode: | Online and Offline |
| Transaction Capacity: | 125.000 |
RADIO FREQUENCY FEATURES |
|
| Working Frequency: | 13,56 Mhz. |
| Reading Distance: | 0 ~ 10 cm |
| Supported Standards: | ISO 14443 A/B |
