X-RAY and Detectors

BARKODES X-RAY AND DETECTOR SYSTEMS

Barkodes' X-Ray and detector systems offer reliable screening solutions for areas requiring high security. Used in airports, public institutions, border crossings, private facilities, and event venues, these systems ensure uninterrupted security management by detecting threats quickly and precisely. Our advanced devices are equipped with features customizable according to usage scenarios.

X-RAY SECURITY SCREENING SYSTEMS

Model 5030A The 5030A X-Ray scanner is developed for the detailed screening of bags and small items. Its dual-energy structure distinguishes between organic and inorganic materials. Low-dosage scanning technology is used for operator safety. Its compact structure ensures high performance even in limited spaces.
Tunnel Size: 507 × 305 mm
Wire Resolution: 34 AWG
Conveyor Speed: 0.20 m/s
Radiation Leakage: Less than 0.1 µGy/h
Max. Load Capacity: 120 kg

Model 6550A

Designed for screening medium-sized luggage and boxes, the 6550A model provides high efficiency with its advanced imaging technology and wide tunnel structure.
Tunnel Size: 655 × 505 mm
Wire Resolution: 40 AWG
Conveyor Speed: 0.20 m/s
Tube Voltage: 150 kV
Max. Load Capacity: 180 kg

WALK-THROUGH METAL DETECTORS (WTMD)

Walk-through detectors identify metal objects on individuals using a multi-zone scanning principle, ensuring safe and rapid screening at entry-exit points.
Up to 33 detection zones (depending on the model).
300 sensitivity levels for each zone.
Audible and visual alarm system.
Remote control and password-protected menu access.
User-friendly interface with LCD screen.
Operating Temperature: -20°C to +65°C.

HAND-HELD METAL DETECTORS (HHMD)

Hand-held detectors allow security personnel to perform manual screening quickly and precisely. With their lightweight structure and high sensitivity, they serve as a complementary element in entrance security.
High metal detection sensitivity.
Audible and Vibration warning system.
Rechargeable or Battery-operated options.
Ergonomic design, portable structure.

Technical Highlights

Dual-Energy Imaging: Material separation (Organic/Inorganic).
High Resolution: 34–40 AWG wire resolution.
Safety: Low radiation leakage (Below 0.1 µGy/h).
Speed: Conveyor speed of 0.20 m/s.
Detection: Multi-zone metal detection.
Control: Password protection and remote control for operator safety.

System Integration and Application Areas

X-Ray scanners and detectors work integrated with turnstile systems, access control solutions, and software infrastructures. By providing centralized management throughout the facility, they offer an end-to-end structure for entrance security. They are especially preferred in public buildings, border security, critical infrastructures, and mass event venues.

Selection Criteria

Tunnel size and load capacity suitable for the usage area.
Scanning speed and resolution values.
Radiation safety and operator protection.
Number of zones and sensitivity levels of detectors.
Energy consumption and resistance to environmental conditions.
Ease of integration and software support.
Comprehensive Security with Barkodes Assurance
Barkodes combines reliable technology, durable mechanical structure, and user-friendly design in X-Ray and detector systems. By developing project-specific solutions, security architectures suitable for every sector are implemented with professional support. Expert technical team support is provided in all processes from installation to commissioning.
